Addressable Executive Block SPK-IB1 for Fire Safety Systems

Available for Import

Addressable Executive Block SPK-IB1 for Fire Safety Automation and Protection

Security and Fire Alarm Systems

Manufacturer: ARGUS-SPEKTR LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Block executive addressable SPK-IB1 is designed to control fire automation devices as part of the automatic fire and security protection system "SPECTR". The device has a relay output. The relay output parameters: - maximum switching voltage - 30 V DC, 250 V AC; - maximum switching current - 8 A. The device output is programmable for triggering by any of the following events: "Alarm", "Fire", "Fault", "Burglary", and have the possibility of introducing a programmable delay of triggering from 3 s to 60 min, as well as limiting the duration of operation up to 60 min.

Specifications

Degree of protection of the shell

IP41

Maximum switching current

8 ?

Operating temperature range

From minus 10 C to plus 55 C

Weight

0.36 kg

Overall dimensions

210x143x38 mm

Average current consumption from SL in standby mode

400 µA
