Copper Cable Terminal T 10-8-5 ZETARUS for Secure Wire End Connections

Cable Accessories

Manufacturer: ZETA OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

Copper tip T 95-12-16 ZETARUS Copper tip T 150-16-20 ZETARUS Copper tip T 185-16-23 ZETARUS Copper tip T 25- 8-7 ZETARUS Copper tip T 2,5 -6-2,6 ZETARUS

Description

Cable copper cable terminations T 10-8-5 are used for termination of wires and cables with copper conductors with a cross-section of 10 mm2 and are fixed on the conductors by pressing.Copper terminations T 10-8-5 are made of copper tube mark M2 and are used for cables up to 35 kV.The copper copper terminals are put on the cable core and pressed with a hydraulic or manual press. This method rigidly binds the lug and the cable end, ensuring a secure connection.T Terminals T are made of M2 copper tube The lug is put on the cable core and pressed with a hydraulic or manual press. This method rigidly binds the lug and the cable end, ensuring a reliable connection.The lugs are designed for 5-6 class of cable core flexibility.

To select the lug 1-3 class of flexibility - use the table.

Specifications

Material

Copper

Cable cross-section 5, 6 flexibility class

10 mm

Cable cross-section 2, 3 flexibility class

10 mm

Climatic version

UHL 3

Inner shank diameter

5 mm

Contact rod diameter

8 mm

Inner diameter

5 mm

Nominal cross-section

10 mm²

Operating voltage

1...35 kV

Connector type

Tip

Availability of coverage

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
