Available for Import
Copper Cable VBSHv-HL for Reliable Electrical Transmission and Distribution
Manufacturer:
EM-KABEL LLC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Available Models
Description
Cable with copper conductors, with insulation made of PVC plasticate, with protective cover made of galvanised steel tapes and hose made of PVC plasticate. Cables are designed for transmission and distribution of electrical energy in stationary electrical installations for rated AC voltage of 0,66; 1 and 3 kV rated frequency of 50 Hz.
Specifications
Mark
VBSHV-XL
Design
according to GOST 31996-2012
Sheath material
PVC
Insulation material
PVC
Cable shape
Round
Material of conductive cores
Copper
Insulation material of conductive cores
PVC
Availability of reservations
Armoured glass
Armor type
Galvanized strip
Material of protective hose (if armor is available)
PVC
Availability of metal screen
No screen
Fire hazard class
?1.8.2.5.4
Cable cross-sectional shape
Round
Design of conductor core(s)
according to GOST 31996-2012
Nominal cross-section of conductive cores
1 mm²
Number of conductive cores
5
Core cross section
1 mm²
Number of cores
5 pcs
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
Share your requirements for a quick response!
Instant response in 15 minutes
Best wholesale prices guaranteed
Direct from manufacturer
Delivery & Payment
Shipping Terms
Delivery Time
Sea freight: 30-60 days (depending on destination)
Air freight: 14-21 days (for urgent orders)
Payment Methods
