Elbrus-2C3 Integrated Circuit System for Advanced Computing Applications
Manufacturer:
MCST OJSC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
System-on-a-chip with two processor cores with 64-bit Elbrus architecture, graphics controller, two RAM controllers, I/O channel controller and a set of peripheral interface controllers to create mobile and embedded systems
Specifications
Type of product according to PP RF 616
Integrated electronic circuits
RAM organization
2 channels DDR4-2600 ecc
Peak throughput of PCIe/WLCC transfer line
16
Peak bandwidth of 16 PCIe/WLCC links
32
SATA/Ethernet Multicontroller Configuration:
4xSATA, or 2xSATA+1xETH1G+1xETH2.5G, or 2xSATA+2xETH1G, or 2xSATA+2xETH2.5G
Number of USB 3.0 ports
4 pcs
Throughput of USB 3.0 transmission line
5
RS-232 Controllers
2 pcs
SPI interface controller
4 pcs
HDA audio interface controller
1 pcs
GPIO/MPV interface controller, lines
16 pcs
Technological process
16 nm
Number of transistors
3
Power supply voltage
3.3 V
Power consumption
20 W
Energy saving technology
Available
I2C interface controller
5 pcs
Architecture
Elbrus, version 6
Number of cores
2 general-purpose Elbrus MCST cores 1 mga2.5 MCST core with 2d-graphics accelerator 1 Imagination PowerVR GC6650 core with 3d-graphics accelerator, hardware video encoding/decoding support
Compute cores clock frequency
2
Compute cores clock frequency
1.8
Compute cores clock frequency
1.6
Graphics core clock frequency
800
Level 1 data cache, per core
64
Level 1 instruction cache, per core
128
Level 2 cache memory (universal)
2
RAM channel bandwidth
6
Possibility to combine into a multiprocessor system with coherent shared memory
no
Video system
RGB, HDMI (2 channels), LVDS. supported resolution: RGB - FULLHD HDMI - 4 K LVDS - 2.5 K
WLINK/PCIe Multicontroller Configuration
PCIEv.3 x16, or PCIEv.3 2x8, or PCIEv.3 x8 + WLCC x8, or PCIEv.3 2x4 + WLCCx8, or PCIEv.3 4x4, or WLCC x16
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
