High-Speed CAN Interface Transceiver K5559IN14ASI for Efficient Data Transmission

Transmitter interface CAN with UREF output are used for high-speed diff.data transmission in accordance with ISO 11898-2 standard and for organisation of half-duplex communication channel with maximum data transmission rate up to 1 Mbit/s.Power supply voltage from4,5 to 5,5 V; Transmitter outputs±40V protection against short circuit and overheating.Fast diph. receiver with a range of input common-phase voltage from -10 to 10 V; 3 modes of operation: "Normal", max. data rate up to 1 Mbit / s; "Control the rate of rise / fall of the output diph.

voltage transmitter", data rate from40 to 500Kbit / s; "Waiting" with reduced consumption, operating range temp. -45-85C.
