Insulated Trailer for Cargo Transport Model 97183 A

Available for Import

Insulated Cargo Trailer for All Weather Transport - Model 97183 A

Heavy Duty Trailers

Manufacturer: NOVOSIBARZ OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Designed for transporting various cargoes requiring protection from atmospheric and/or temperature effects on roads of all categories of the general road network. Technically permissible maximum vehicle weight is 35 - 44 tonnes. The semi-trailers have a coupling pin with a diameter of 50.8 mm or 88.9 mm.

Loading space - van body or isothermal van body, single-section, two-section or three-section. Coupling kingpin with diameter 50.8 mm or kingpin with diameter 88.9 mm. Axles 9 tonnes manufactured by Plant Ltd.

or Axle unit 26 tonnes. BPV-Ost Ltd. Tyres 385/55 R22,5; 385/65 R22,5 manufactured by JSC "Kordiant"/ LLC "Nizhnekamsk Tyre Plant CMK".

Wheel discs manufactured by OOO "AccuRide Wheels Russia" or PJSC "ChKPZ". Receiver manufactured by OOO TD "AUTOTECHNOLOGIA". Lighting equipment manufactured by OOO "Atlanta".

Floor level crane manufactured by VBK Vostok Ltd.

Specifications

Type of semi-trailer

van

Width

2550...3000 mm

Maximum length

17500 mm

Axle load capacity

8...9 t

Maximum height

4300 mm

Base machine type

truck

Rear track

1845...2068 mm

Front track

1845...2068 mm

Base

3150…9400 + 1300…2050 + 1300…2050

Technically permissible maximum load on the coupling ball bar

10787-16671

Technically permissible maximum mass of the vehicle

35000...44000 kg

Vehicle kerb weight

7000...16000 kg

Scope of application

Designed for transporting various cargoes requiring protection from atmospheric and/or temperature effects on roads of all categories of the general road network

Reliability parameters

Average service life before the first major overhaul under the first category of operating conditions in compliance with all operating and maintenance rules specified in the operating manual - not less than 100,000 km; MTBF under the first category of cond

Warranty period

B1/B8 2100/900 MHz

Ergonomic parameters

Paint coatings used for the exterior surfaces of semi-trailers vans, allow the possibility of underpainting or repainting them with natural drying paints, the force required to lift the spare tire does not exceed 500 N (50 kgf). When applying

Climatic version

UHL

Number of axles

3 pcs

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
