Available for ImportKSO Oniga Series Cells 10, 20 kV for Efficient Power Distribution
Manufacturer:ELTEHNIKA OJSC
Price:Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
"Onega" 10,20 kV Series CSR prefabricated single-sided service cells of "Onega" series are designed for completing switchgears (switchgear) with voltage of 10,20 kV of three-phase alternating current with frequency 50 Hz, in networks with isolated or earthed through arc-extinguishing reactor or resistor neutral.
Specifications
Width
300...750 mm
Height
2010...2235 mm
Depth
1050 mm
Nominal voltage
10...20 kV
Highest operating voltage
12...24 kV
Rated current of busbars
630...1250 A
Rated current of line terminals
630...1250 A
Rated current of fuses
up to 200 A
Rated current of circuit breakers
1000...1250 A
Rated current of load disconnectors
630 A
Rated current of disconnectors
630...1250 A
Rated current of current transformers
5...1250 A
Rated tripping current of circuit breakers
20000 A
Thermal endurance current at 3s flow time, kA
20000 A
Electrodynamic resistance current
51000 A
Rated voltages of control and auxiliary circuits, at direct current
24...220 V
Service life
30 year
Degree of protection according to GOST 14254
IP31
Weight
Up to 800 kg
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
