Available for Import

LTE Cat.6 Router with SIM Injector Support - Kroks Rt-Pot RSIM DS eQ-EP for Signal Enhancement

Communication Devices

Manufacturer: KROKS PLUS LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

This illuminator when used with a satellite dish provides signal amplification up to 30 dB. It can also work as an independent antenna and give 8-9 dB. The operating frequency range is 1700-2700 MHz.

The transmitter supports MIMO technology and works in 3G/4G standards. The sealed housing reliably protects from unfavourable weather conditions. The transmitter is equipped with a m-PCI-modem Quectel LTE cat.6, which supports 3G/4G standards and operates in the frequency range of 1700-2700 MHz.

The modem's reception speed is limited by the LAN port bandwidth and is 100 Mbps. The modem itself meets the requirements of LTE-Advanced technology and according to its technical characteristics is capable of providing reception up to 300 Mbit/s. The kit includes a SIM-injector for two SIM-cards.

This makes it possible to perform a quick and convenient installation of sim cards. Two more slots for SIM-cards are located inside the body of the illuminator on the router board. A total of 4 sim cards can be installed.

Specifications

Equipment

Router KROKS Rt-Pot RSIM DS eQ-EP

MIMO support

MIMO 2x2

Operating frequencies

3G - WCDMA - B1/B3 - 2100/1800 MHz

Modem baud rate

4G - up to 300 Mbit/s (receive) / up to 50 Mbit/s (transmit)

Ports and interfaces

Ethernet ports - 1 pc, 100 Mbps

Memory

Ram 64 MB Rom 16 MB

WiFi transmitter power

Wi-Fi standard

Processor frequency (CPU)

580 Mhz

Power Type

Passive PoE 24 V

LAN port speed

10/100

Number of LAN ports

1 pcs

Number of SIM cards

2 pcs

Number of modems

1 pcs

LTE Category

LTE cat.6

Interfaces

Standard

3G, HSDPA, HSPA+,DC-HSPA+, 4G, LTE-FDD, LTE-TDD

Antenna connector

TS9

Length

250

Width

110

Height

110

Weight

960

Mark

Kroks

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
