MKT Pump-Filter Module (TS-1) for Effective Fuel Filtration Operations

MKT pump-filtration module (TS-1) 380.100.0,25.25.3 (fuel filtration unit, AFT) is designed to perform the following operations: Aircraft refuelling from ground tanks. Aircraft fuel filtration with water separation. Aircraft fuel metering by volumetric method.

Dosed injection of anti-crystallisation fluid (ACF). AFT is manufactured in two configurations with and without dosed injection of anti-crystallisation fluid. The AFT module is an optional module and can be purchased separately.

The main AFT module has the following characteristics: Capacity: 100 l/min. Power consumption: 2.2 kW. Voltage: 380 V.

/ 220 V (requires MKT SHUN 380/220 3kW) Coarse filter: 100 µm. Fine filter with water separation: 3 µm. Volumetric fuel metering with mechanical counting device: measurement error 0,25 %.

Operating temperature from -40 to +45 gr The main module of AFT includes: Electric pump unit. Filtration and water treatment system.
