Description

The R65 type 1/11 wooden bar track switch is designed for transferring rolling stock from one track to another. The crossing is interchangeable with the switch of the project 2764. The switch is equipped with flexible shackles and terminals for elastic fastening of frame rails.

The crossbar is prefabricated with improved mating of cast and rail parts. The counter rail is not connected to the track rail. The shackles and frame rails are HFI hardened.

The crossing is made on pads with high flanges. The R65 type 1/11 grade 1/11 type R65 switches of project 2773.00.000-02/03 are manufactured in the following versions: 2773.00.000-02 - right; 2773.00.000-03 - left.

Specifications

Cross type by construction

Team

View in the direction of a side or crossing track

Left, right

Rail type

?65

Cross brand

1/11

Arrow design

With flexible sharps

Type of single transfer

Ordinary

View

Single

Cross type by angle

Spicy

Type of product according to PP RF 616

Track equipment and devices and their parts

Type of timber

wooden

Type

?65

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
