R65 Type Switch with Reinforced Rotating Core Model 2561.00.000-05 Available for Import

R65 Type Switch with Reinforced Core for Track Switching Applications

Wide Gauge Track Switches
Manufacturer: NSZ OJSC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Available Models

P65 type 1/11 arrowhead crossing with crossing arm with reinforced swivelling core of the project 2561.00.000-04 P65 type 1/11 arrowhead crossing with crossing arm with reinforced swivelling core of the project 2561.00.000-04

Description

Designed for transfer of rolling stock from one track to another. It is used on the main tracks of railway lines with mixed freight and passenger train traffic and speeds of passenger trains on the straight track up to 160 km/hour. Design features: translations: on the crutch and terminal fastening; switches: flexible shackles; pads with pads on the rivet connection; connecting rods - adjustable; crosses: cross with a continuous rolling surface with a reinforced rotary core.

Specifications

Cross type by angle
Spicy
View
Single
Type of single transfer
Ordinary
Arrow design
With flexible sharps
Cross brand
1/11
Rail type
?65
View in the direction of a side or crossing track
Left
Cross type by construction
With continuous rolling surface
Type of product according to PP RF 616
Track equipment and devices and their parts
Type of timber
wooden
Save Your Time

Share your requirements for a quick response!

Instant response in 15 minutes
Best wholesale prices guaranteed
Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
