Radio Channel Dispatcher Control System SPMD-16 for Reliable Multi-Channel Communication

Switching Communication Systems

Manufacturer: ERICS CONNECT LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The system of dispatch control of radio channels SRMD-16 is designed to provide equal access of up to 32 dispatchers/operators of one receiving and transmitting centre to 16 radio channels. The system provides: conflict-free conduct of bilateral radio conversations with subscribers of different radio channels by several dispatchers/operators; connection of up to 32 operator consoles; control of up to 16 radio channels from each operator's workplace; simultaneous listening to 4 selected radio channels at the operator's workplace. The system includes: operator console software SRMD-16 (up to 32 pcs.); base unit of central controller CK-BB SRMD-16 with boards of radio channels CK-PRK-4 SRMD-16 (up to 4 pcs.) and boards of operator consoles CK-PPO-4 SRMD-16 (up to 8 pcs.).

Specifications

Type of power supply

AC/DC

Number of power supplies

1 pcs

Type of power supplies

fixed

Power supply

Built-in

Switch type

Managed

Type of data transmission

Completeness

Operator console PO SRMD-16; base unit of central controller CK-BB SRMD-16; radio channel board CK-PRK-4 SRMD-16; operator console board CK-PPO-4 SRMD-16.

Maximum number of consoles in the System

32 pcs

Maximum number of controlled channels per operator workstation

Maximum number of simultaneously listened radio channels at the operator's workplace

Number of slots for radio channel cards in the central controller base unit

4 pcs

Maximum number of radio channels supported by the radio channel card

Maximum number of operator consoles supported by the operator console card

4 pcs

Average service life of the System

5 year

Number of slots for operator console cards in the central controller base unit

8 pcs

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
