Vacuum Electric Thermal Installation KB 142 for Tantalum Sintering

Vacuum electrothermal unit KB 142 is designed for sintering of tantalum anodes of shaft type without elements of vacuum system at temperature not more than 2100C. The unit contains: a heating chamber, including a cylindrical vertically located housing made of stainless steel 12?18?10?, closed from the upper and lower ends with covers (inside the heating chamber there is a heating block with heaters and heat insulation block. The body and cover have water cooling jackets); control cabinet; automated vacuum system; water cooling system; system of air or neutral gases intake into the working chamber; wiring; spectral ratio pyrometer.

To measure, regulate and record the temperature in the working space in the body of the furnace provided spigots for one regulating and control retractable thermocouples BP(A-1).
