Vehicle Motion Parameter Measurement System "RAPIRA-M" for Speed and Location Tracking
Manufacturer:
OLVIA LLC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Available Models
Description
Measurers of vehicle movement parameters "RAPIRA-M" is designed for:
- measuring the speed of vehicles (hereinafter referred to as TC) in the IP control zone;
- measurement of vehicle location in the IP control zone;
- measurement of time synchronised with UTC(SU) time scale, corresponding to the moment of measuring the speed and location of the vehicle;
- measurement of coordinates of the UUT location;
- classification of vehicles by length;
- calculation of the number of vehicles that have passed the control zone during the time interval.
- measuring the speed of vehicles (hereinafter referred to as TC) in the IP control zone;
- measurement of vehicle location in the IP control zone;
- measurement of time synchronised with UTC(SU) time scale, corresponding to the moment of measuring the speed and location of the vehicle;
- measurement of coordinates of the UUT location;
- classification of vehicles by length;
- calculation of the number of vehicles that have passed the control zone during the time interval.
Specifications
Operating frequency of IP radiation, GHz
24.15±0,1
Number of TC classifications by length, not less than
6 pcs
Rated DC supply voltage
B1/B8 2100/900 MHz V
DC supply operating voltage range
8...18 V
Consumption power at rated supply voltage, not more than
8 W
Ambient air temperature
-50...80 °C
Permissible relative humidity at 25°C
98 %
Atmospheric pressure
60...106.7
Degree of protection
IP 66/67
Weight, not more
0.6 kg
Overall dimensions (L*W*H), not more, mm
130*85*70
Measurement range of vehicle speed
1...350
Measuring range of distance from the UUT to the vehicle, m
5...150
Measuring range of angles on TC in horizontal plane, ?º
-10...10
Measuring range of angles on TC in vertical plane, Cº
-20...20
Tolerance limits of absolute error of angle measurements on TC, ?º
±1
Limits of permissible absolute error of measurement of distance from UUT to TC, m
±1
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
