Versatile Lathe Machine for Turning and Thread Cutting - Model 16P25-1.5
Manufacturer:
RSZ LLC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
The machine is designed to perform a variety of turning operations, including thread cutting: metric, modular, inch and pitched threads.
Specifications
Type of product according to PP RF 616
Turning and screw-cutting machines (universal, with CNC, CNC)
Height
1500 mm
Width
1345 mm
Length
3325 mm
Largest diameter of the workpiece to be mounted and machined above the slide
250 mm
Largest diameter of the workpiece to be machined above the bed
500 mm
Largest diameter of the workpiece to be mounted above the bed
500 mm
Longest workpiece length
1500 mm
Spindle end of the spindle headstock according to GOST 12593-72
11?
Maximum longitudinal movement of the carriage
1435 mm
Maximum transverse movement of the carriage
325 mm
Maximum movement of the carriage tool slides
150 mm
Spindle speed limits
16...2000
Pitch limits of machinable threads, metric
0.5...112 mm
Step limits of machinable threads, inch threads
56-0.5 thread count per 1"
Pitch limits of machined threads, modular
0.5-112 module
Pitch limits of machinable threads, pitch
56-0.5 pitch diametral
Speed of fast longitudinal movements of the carriage
3000 mm/min
Speed of rapid transverse carriage movements
1500 mm/min
Highest torque on the spindle
1.0 kNm
Highest cutting force Pz
18500
Main motion drive motor power
11 kW
Total power of electric motors installed on the machine tool
11.69 kW
Roughness of the conical surface of the sample product
Ra2.5 µm
Machine accuracy class according to GOST 8-82
?
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
