High-Frequency Twisted Pair Cable KSVPP-5e 8x2x0.48 for Reliable Data Transmission

Construction: The cores are made of soft copper wire in polyethylene insulation, twisted in pairs with steps, not equal and not multiples of each other.Pairs are twisted in the core by unidirectional twisting.It is allowed over the twisted core of cables overlapping belt insulation from PET tape.On top of the core there is a screen made of aluminopolymer tape with a contact conductor made of tinned copper wire 0,4 mm in diameter. On top of the screen there is a sheath made of light-stabilised polyethylene (HDPE) with an external load-carrying element twisted from seven galvanised steel wires, connected by a jumper. Field of application: The cable is designed for horizontal and vertical external laying on the walls of buildings, suspension on overhead communication lines and pulling between supports or buildings, for operation in the frequency range up to 100 MHz (category 5 and 5e according to GOST R 54429-2011) and ISO / IEC 11801.

Cables are manufactured in climatic version UHL, categories of placement 1, 2 according to GOST 15150.
