Universal Worm Gear Reducer UD-NRV for Reliable Performance in Various Positions

The UD-NRV series worm gearbox is characterised by a modernised universal housing. which allows the gearbox to be mounted in any position. Simple and robust design offers high performance and quiet operation.

Thanks to unified connection dimensions, they can be used as a replacement for gearboxes from other companies. gearboxes from other companies. Characteristic features of UD-NRV worm gearboxes: 9 gearbox sizes with outputs of 0.06 - 15 kW (30 - 40 - 50 - 50 - 63 - 75 - 90 - 110 - 130 - 150) gear ratio range 5 - 100; maximum output torque - 1400 N-m, permissible radial load - 16500 N; the worm gearbox housing is painted with polyepoxy paint from size 030 onwards.

blue (RAL 5010) in accordance with DIN 1843; Gearmotor housing up to size 090 is made of aluminium alloy; gearmotor housing sizes 110 to 150 are made of grey cast iron of cast iron type G200, FEM-machined...
