Horizontal Axial Pump OG5-87A for Efficient Water Transfer

The pump is an axial horizontal single-stage pump with cantilever arrangement of the impeller designed for pumping water with maximum density of solid particles 2200 kg/m3 with temperature not more than 35°C. The pump rotor rotates in two radial double row roller bearing supports lubricated with liquid grease. The axial force from the reaction of water and rotor mass is taken up by a thrust tapered roller bearing. The direction of rotation of the rotor is clockwise when viewed from the motor side. Torque transmission from the electric motor shaft to the pump shaft is realised by means of a sleeve-finger coupling.
