Universal Pipe Cutting Machine SA983C for Precision Metalworking

Manual Metal Lathes

Manufacturer: SASTA PJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Universal pipe cutting machine CA983C - specialised equipment designed for processing pipe joints, can also be used for all kinds of turning work. Easy to use pipe cutting machine designed for processing of long pipes and pipe joint parts with diameter up to 340 mm, used for oil and natural gas production and transportation. It is also suitable for all types of turning operations, including cutting metric and inch threads, including tapered threads. It is equipped with a hydraulic mechanism for automation of one threading pass (hydro-bounce) during thread cutting both in manual mode and in a cycle. The machine has modifications CA983C010, CA983C020, CA983C030.

Specifications

Type of product according to PP RF 616

Turning and screw-cutting machines (universal, with CNC, CNC)

Height

1675 mm

Width

2050 mm

Length

3640 mm

Accelerated Z-axis travel (longitudinal movement)

5300 mm/min

Tailstock quill taper

Morse 6

Diameter of tailstock quill

120 mm

Moving the tailstock quill

240 mm

Turning mechanism

Manual

Cutter section

32x32 mm

Number of tool positions

4 pcs

Spindle bore diameter

?340

Chuck type

Mechanized

Chuck diameter

ø720 (ø630)* mm

Main engine power

15 kW

Speed control

Step, 12 steps

Maximum torque

3000 nm

Spindle speed

8 - 355 rpm

Pitch limit of threads to be cut, inch

28-1 threads per inch

Pitch limit of the thread to be tapped, metric

1-28 mm

Working range of longitudinal feed rates

0,09 - 2,67 mm/rev

Working range of cross feeds

0,042 - 1,179 mm/rpm

Accelerated movement in X axis (transverse movement)

2200 mm/min

Z-axis travel (longitudinal movement)

1000/2000/3000 mm

Travelling in X axis (transverse movement)

500 mm

Maximum length of workpiece to be machined with tapered ruler

500 mm

Largest diameter of the workpiece to be machined above the slide

450 mm

Largest diameter of the workpiece to be mounted above the bed

830 mm

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
