Interface Repeater RA-30 "RUBETEK" for Extending CAN Lines in Indoor Systems

Fire Alarm Detectors

Manufacturer: RUBETEK RUS LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

RA-30 is designed for increasing the length, merging and branching of CAN line in "RUBETEK" systems.RA are designed for indoor installation, in places protected from atmospheric precipitation, aggressive media and dusts, as well as in especially explosion and fire hazardous areas.

Specifications

Power supply from a DC source with voltage

24 V

Consumption current

0.047 A

Communication interface

CAN

Number of CAN interfaces

2 pcs

Maximum number of repeaters in series in one CAN line

4 pcs

Maximum number of connected CAN network repeaters

30 pcs

Operating temperature range

-25...55 °C

Relative humidity at + 40 deg. ?

0...93 %

Degree of enclosure protection

IP20

Dimensions (L x W x H), mm

115x90x40

Weight, not more

0.12 kg

Average service life

10 year

Average MTBF

60000

Probability of failure-free operation in 1000 h

0.98

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
